Spesifikasi

ENGINE :
Model : 3C100LFU; Type : 3Cyl., In-line Vertical, Water-cooled 4-cycle diesel engine (NTE); Engine Gross : 22 (16.4) HP(KW); Displacement : 61.45 (1,007) cu.in.(cc); Rated Revolution : 2,800 rpm; Fuel Tank Capacity : 7.4 (28) u.s.gal(ℓ)

DRIVE TRAIN :
Type : Belt CVT; Gear Range : Low, High, Neutral, Reverse; Ground Speed (km/h) : 0-25 (0-40) mph(km/h); Brake : Front/Rear Hydraulic Dry Caliper Disc

SUSPENSION :
Front Suspension : Independent, MacPherson Strut type; Rear Suspension : Independent, Double A-Arm (Wishbone type)

STEERING :
Type : Rack & Pinion

DIMENSIONS :
Length : 112.3 (2,852) in.(mm); Width : 60.7 (1,543) in.(mm); Height : 76.4 (1,940) in.(mm); Max Wheel Tread Front : 49.7 (1,262) in.(mm); Max Wheel Tread Rear : 48.3 (1,228) in.(mm); Wheelbase : 76.4 (1,940) in.(mm); Weight : 1,687 (765) lbs.(kg); Ground Clearance : 12 (304) in.(mm); Towing Capacity : 1,300 (590) lbs.(kg); Payload Capacity : 1,598 (725) lbs.(kg); Turning Radius : 13.1 (4.0) ft.(m)

CARGO BED :
Length x Width x Depth : 38.6 (980) x 56.2 (1,427) x 11.5 (293) in.(mm); Bed Capacity : 1,102 (500) lbs.(kg)

TIRE SIZE :
Front Heavy Duty Worksite : 25x10-12; Front Turf : 26x10.5-12; Front ATV : 25x10-12; Rear Heavy Duty Worksite : 25x11-12; Rear Turf : 26x10.5-12; Rear ATV : 25x11-12; Seat Capacity : 3 Seat Bench; Dump Box Actuation : Manual; Front Guard : Std.; Body Color : MECHRON Orange / Green; Hydraulic Bed Lift : Opt.; Hydraulic Utility Valve : Opt.; Speedometer : Std; Rear Hitch Receiver : Std.; Winch Bracket : Opt
