Spesifikasi

ENGINE :
Model : 1104C-44TT; Type : 4Cyl., In-line Vertical,4Cyl., In-line V Water-cooled; Engine Gross : 89.2(66.5) HP(kw); PTO : 72.7(54.2) HP(kw); Displacement : 4,399(269) cc(cu in.); Rated Revolutionted Revolution : 2,200 rpm; Fuel Tank Capacity : 120(31.7) ℓ(US gal)

DRIVE TRAIN :
Clutch : Dry single plate-single stage type; Transmission : synchro mesh(Main), constan mesh (range); Speeds : 16 X 16; Differential Lock : Rear standard; Brake : Wet disc type; PTO : Independent; PTO Rear : 540/1.000 rpm

HYDRAULIC SYHYDRAULIC SYSTEM :
Pump Capacity (max. Flow Rate) : 48.4(22), 30.8(14) lpm(cc/rev); 3 - Point Hitch : Cat.II; Lift Capacity at lift poin : 2,400(5291) kg.f(lbs); Hydraulic Lift Control System : Position, draft, mixed control; Steering : Hydrostatic power steering

TIRE SIZE :
Front Ag : 12.4-24, 8PR; Rear Ag : 18.4-34, 8PR

TRAVELING SPEEDS :
Forward : 0.77~34.62 (40~21.51) km/h(mph); Reverse : 0.75~35.04 (47~21.77) km/h(mph)

DIMENSIONS :
Overall Length (includes 3-pt hitch) : 4,120(162.2) mm(in.); Overall Width (minimum tread) : 2,000(78.7) mm(in.); Overall Height (from top of ROPS) : 2710 (106,7) mm(in.); Wheelbase : 2,305(90.7) mm(in.); Min. Ground Clearance : 475(18.7) mm(in.); Tread Front : 1,510(59.5) mm(in.); Tread Rear : 1,535(60.4) mm(in.); Min. Turning Radius (with brake) : 3,900(153.5) mm(in.); Weight with ROPS and AG Tire : 3485 (7683) kg.f(lbs)
