Spesifikasi

Engine :
Engine Model : 4B243DL-A1; Engine Gross Power : 45 hp (33.6 kW); Rated Speed : 2,600 rpm; No. of Cylinders : 4; Fuel Type : Diesel; Engine Net Power : 43(32.1) HP(kw); Total displace : 2435 cc (cu); Fuel tank : 45(11.9) ℓ(us gal)

PTO :
Maximum PTO Power : 38.5/2300 HP/rpm(KW); Rear PTO : Independent; rpm : 540 / 750

HYDRAULIC :
3 Point Lift Control Type : Position, Draft, Mixed Control; 3-point hitch type : Category I; Lift capacity at lift point : 1360 kg.f(lbs.); Lift capacity at 24 in.behind lift point : 1232 kg.f(lbs.); No.of standard remote valve's ports (Rear) : 2

DRIVE TRAIN :
Transmission : Manual; No. of speeds : 8F8R; shuttle Type : Synchro shuttle; Steering :
Hydrostatic Power Steering; Main Clutch type : Dry single

TRAVELING SPEEDS :
Forward : 2.17 - 27.9 km/h(mph); Reverse : 2.11 - 27.2 km/h(mph)

DIMENSIONS :
Overall length(includes 3-pt hitch) : 3157(124.3) mm(in.); Overall width(minimum tread) : 1596(62.8) mm(in.); Tread width Front 4wd : 1254(49.4) mm(in.); Tread width Rear : 1251(49.3) mm(in.); Overall height(with ROPS) : 2246(88.5) mm(in.); Wheel base : 1810(71.3) mm(in.); Ground(Crop) clearance : 347(13.7) mm(in.)

TIRE SIZE :
AG. Tire Front : 8-16; Rear : 13.6-24
