Spesifikasi

ENGINE : Daedong
Model : 3B183LWM-E1; Engine Gross Power : 35(26.1) HP(kw); Rated revolution : 2,600 rpm; Total displace : 1,826 cc (cu); Cooling system : Water Cooled; Fuel tank : 34 ℓ(us gal)

PTO :
Maximum PTO Power : 30.8/33.5 HP; PTO Fuel Consumption : (268) ℓ/h(gph); Rear PTO Type : Live; Revolution : 540/750 rpm


HYDRAULIC :
3 Point Lift Control Type : Positon; Implement Pump : 27.04 ℓ /min(gpm); Power steering pump : 17.36 ℓ /min(gpm); Total hydraulic flow : 44.4 ℓ /min(gpm); 3-point hitch type : Category 1; Lower Link type : Ball; Lift capacity at lift point : 1,030 (2,270) kg.f(lbs.); Lift capacity at 24 in.behind lift point : 740 (1,631) kg.f(lbs.); Drawbar type : Bar; No.of standard remote valve's ports (Rear) : 4 Port

Drive Train :
Transmission : Manual; Main gear shift x range gear shift : 3 x 3; No. of speeds : 9 x 3; Steering : Hydrostatic Power Steering; Brake type : Wet disc type; Main Clutch type : Dry dual; Mechanical differential lock : Rear Standard

Traveling Speeds :
Forward : 1.52~23.56 km/h(mph); Reverse : 1.90~15.39 km/h(mph)

Dimensions :
Overall length(includes 3-pt hitch) : 3,070 mm(in.); Overall width(minimum tread) : 1,400 mm(in.); Overall height(with ROPS) : 2,650 mm(in.); Wheel base : 1,670 mm(in.); Ground(Crop) clearance : 340 mm(in.); Turning radius(w/brake) : 2,450 mm(in.); Weight with ROPS : 1,195 kg.f(lbs.); AG. Tire Front : 7-16; AG. Tire Rear : 11.2-24
