Spesifikasi

Engine :
Model : 3A139LWB; Type : 3Cyl., In-line Vertical, Water-cooled 4-cycle diesel engine; Engine gross : 28 HP; PTO Manual : 24.2 HP; PTO HST : 22.3 HP; Displacement : 1,393 cc; Rated revolution : 2,600 rpm; Fuel tank capacity : 25 ℓ

DRIVE TRAIN :
Clutch : Dry single; Transmission : Manual & Hydrostatic; Speeds Manual : 6F2R; Speeds HST : INF. 2; Differential lock(rear) : Standard; Brake : Wet disc type; PTO Manual : Transmission; PTO HST : Live; Rear : 540 rpm; Mid(Optional) : 2,000 rpm

HYDRAULIC SYSTEM :
Pump : Gear(Tandem); Total Pump capacity at maximum flow : 42.9 ℓ/min; 3-point hitch : Cat.I; Maximum lifting capacity(24˝ behind lift point) : 739(546) kg; Hydraulic lift control system : Position control; Steering : Hydrostatic Power Steering

TIRE SIZE :
AG Tire Front : 7-12/6; AG Tire Rear : 11.2-16/6; Turf Tire Front : 23×8.5-12; Turf Tire Rear : 33×12.5-16.5

TRAVELING SPEEDS :
Forward Manual : 1.20-17.34 km/h; Forward HST : 0-17.15 km/h; Reverse Manual : 1.48-6.73 km/h; Reverse HST : 0-12.01 km/h

DIMENSIONS :
Overall length(includes 3-pt hitch) : 2,790 mm; Overall width(minimum tread) : 1,250 mm; Overall height(from top of ROPS) : 2,335 mm; Wheelbase : 1,520 mm; Min. ground clearance : 340 mm; Tread Front : 960 mm; Tread Rear : 950 mm; Weight with ROPS : 1,025 mm
